GTR-17 Generator Controller with Auto Start Stop Function Max 5W
YOU MAY ALSO NEED
GTR-17 Generator Controller with Auto Start Stop Function Max 5W
Part Number:
GTR-17,GTR17
See Details:
Brief introduction:
The GTR-17 Generator controller equipped with Auto Start/Stop functions, protections, alarm and annunciation etc. Monitoring and protections include: Running, Over Speed, High Water Temperature, Low Oil Pressure, Over Crank, Emergency Stop, and Low Battery. All outputs function executed by a set of traditional relays which make it possible to support heavy power handling capability. It is designed to control engine by a key switch. User only needs to switch the key to the Manual position then the system will carry out whole functions according your settings. Besides, the BC168 applied with a high security continental terminal connector that provides easy plug-in and removal.
Specification :
DC Supply: DC 8-36V
Power Consumption : MAX 5 W
Measuring Frequency: 0-80 Hz (AC Volt: 25 V - 300 V)
Relay Output Start Output: 2 A
Valve Output: 2 A
Idle/Pre-heat Output: 2 A
Alarm Output: 2 A
Stop Output: 2 A
Dimension (W*H*D): 72mm*72mm*58mm
Panel Cut-Out (W*H): 68mm*68mm
Ambient Temperature Range : -10℃ - 85℃
| Part Number | GTR-17,GTR17 |
