Magnetic Pick Up MSP676 Rotate Speed Sensor Generator Parts

sku #
mymro023393
Part #MSP676

Magnetic Pick Up MSP676 Rotate Speed Sensor Generator Parts for sale on our website.
In addition to Magnetic Pick Up MSP676 Rotate Speed Sensor Generator Parts, you can also buy other models or other parts of Excavators, Forklift, Aerial Work Platforms AWP and etc. on our website.

50000+ Parts in Stock
50000+ Parts
in Stock
30 Days Money Back
30 Days
Money Back
2-7 Days Fast Delivery
2-7 Days
Fast Delivery
100% Secure Payment
100% Secure
Payment
Our Price
$24.32
SUPPORT
Shipping Policy

We ship fast so you can get on the road that much faster. Check out our Shipping Policy for more details.

Return&Exchange

We’re only happy if you’re happy. If you’re not entirely satisfied with your order, you may be entitled to a refund. Check out our Return & Exchange for more details.

Magnetic Pick Up MSP676 Rotate Speed Sensor Generator Parts

Part Number:
MSP676

Introduction:
Rotate speed sensor,
speed sensor,
generator sensors
Item: MSP676
Pickup Length: 5.00"
Thread Length: 4.625"
Lead Length: 12.00"
Thread Size: 5/8-18 UNF-2A
Drill Size: 37/64

Application:
1.The magnetic speed sensor is mounted in the ring gear case or flywheel bell housing of the engine.
2.The threaded hole for the speed sensor should be perpendicular to the centerline of the crankshaft and centered over the ring gear teeth.
3.A spot face should be present to provide a flat surface on which to anchor the locknut.
4.With the engine stopped, screw the speed senor in until it touches a gear tooth, then back it out 3/4 of a turn and secure it with the locknut.
5.Any ferrous gear may be used as long as the frequency and amplitude of the resulting signal meet the speed control unit specifications.
6.The wire leads should be twisted for their entire length from the magnetic speed sensor to the control unit.
7.The leads may need shielding if they are longer than 10 ft. (3m), or if external interference is present.
8.Do not connect either of the speed sensor leads to anything but the speed control unit used. The shield should not be connected at the speed sensor end.

More Information
Part NO.MSP676
